Pre-configured IP65 metal consumer unit for the protection of a 7.4kW electric vehicle charging point. Includes Type 2 SPD, 63A RCCB, 40A MCB and 100A mains switch. Modern design with a blind access door to conceal internal circuit breakers. Heavy duty construction.

Brand Name	Lewden
Material	Pre-Galvanised Steel
Manufacturer Model No	PRO65-REV40AS
Type	Consumer Unit
Waterproof	IP65
Busbar Type	Floating Busbar
CSU Populated/Unpopulated	Populated
Cable Entry Points	Top, Bottom, Side & Rear
Consumer Unit Type	EV Charger
Current Rating	32 A
DIN Rail Supplied	DIN Rail Supplied
Fixings Supplied	Brackets & Fixings Supplied
IK Rating	IK09
IP Rating	IP65
Integrity	Non High Integrity
MCBs Supplied	MCB
Mains Switch Rating	100A Mains Switch
Manufacturer Guarantee	1 Year Guarantee
Model No	PRO
No. of MCBs Supplied	1 x Type B MCB (40A)
No. of Populated Ways	6
No. of RCBOs Supplied	0 x RCBOs
No. of RCDs Supplied	1 x Type A 63A 30mA RCCB
No. of SPDs Supplied	40kA Type 2 SPD
Pack Size	1
Pieces in Pack/Case	1
Power Voltage Supply	230/400 V
Product Depth	105 mm
Product Height	264 mm
Product Type	EV Consumer Unit
Product Width	168 mm
RCBOs Supplied	No RCBOs Supplied
RCD Type	Type A
RCDs Supplied	RCD
SPDs Supplied	SPD
Temperature Range	-5 to 40 °C
Total No. Module Spaces When Empty	6
Total Product Weight	2.460 kg
Way	6 Way
