Brand Name	Lewden
Manufacturer Model No	E10-1B10
Breaking Capacity (Inc)	10 kA
CSU Device	MCBs
Curve Type	B Curve
Incomer Fitting Type	DIN Rail Mounted
Manufacturer Guarantee	1 Year Guarantee
Model Name	E10
No. of Phases	Single-Phase
Number of Poles	Single Pole
Pack Size	1
Pieces in Pack/Case	1
Product Type	MCB
Rated Impulse Withstand Voltage (Uimp)	6 kV
Rated Operational Current (In)	10 A
Rated Operational Voltage (Ue)	230 V AC
Suitable Cable Size	1-25 mm²

The Lewden range of circuit protection devices are designed and tested for use with Lewden branded distribution boards. This device must be installed by a skilful electrician in accordance with the latest edition of the IET wiring regulations for electrical installations BS7671

Brand Name	Lewden
Colour	White
Material	N/A
Manufacturer Model No	E10-1B10
Wear Type	N/A
Type	Miniature Circuit Breaker
Certifications Met	EN 60898-1:2019, BS EN 60898-1:2019, IEC 60898-1:2015, IEC 60947-2:2016
Country of Origin	N/A
Protects From	overload, short circuit and infrequent switching of circuits
Waterproof	N/A
Number of Pockets	N/A
Width	17.8mm
Waist Size	ab58cj13gv
Poles	Single
Height	88mm
For Use With	Lewden Distribution
Depth	69.5mm
Current Rating	10 A
Breaker Type	Type B
Supplier Part Number	E10-1B10

Brand Name	Lewden
Manufacturer Model No	E10-1B10
Type	Circuit Breaker
Certifications Met	EN60898-1
Protects From	overload & short circuit
Current Rating	10A
Depth	69.5mm
Dimensions	(H)88 mm x (W)17.8 mm x (D)69.5 mm
Guarantee	2 Years
Height	88mm
Mounting	DIN Rail
Number of Poles	Single Pole
Packaging Types	Each
Short Circuit Rating	10kA
Tripping Characteristics	B Curve
Unspsc V18	39121603
Unspsc V24	39121603
Voltage Rating	230V
Weight	0.06kg
Width	17.8mm
